57: Wow! Somebody else thinks like me...


This author/builder operated with a slightly different philosophy than did I, but we both built tiny cabins (he used only salvage material, and I used only local stuff) of a Thoreauvian nature and blogged about it. I relied on loads of friends for their healthy backs, expertise, and good company. He worked alone most of the time. His hit-count (on the blog) is even similar to ours!

Here!


I found out about it here, on this amazing capture point and resource devoted to projects like mine!

55: Celebrating with a Kayakerator!



Saturday, lots of the folk who helped me along the way or even followed this blog came up the holler to raise a glass to a dried-in cabin! For the occasion, Sean, maker of phenomenal craft beers, brought the Kayakerator (TM) to celebrate -- our organization,Tuckaseegee Brewing Co-op, for which he is the brewmaster, uses this craft, donated by Dinver at Pyranha in Asheville, to dispense its peerless product, in this case one keg of Panthertown Pale Ale and one of Bonas Defeat IPA, both owing their beery goodness to Sean's craftmanship as well as the hops he grows right here in Jackson County.

I'll post a description of my building and completion process in a few days; meanwhile, here are some pictures from Saturday -- more of the party to follow in another post.

Sean with the guts of the Kakakerator

Mark approves!
Josh says, "Hey! this looks like MY BURN! OK, it's not. whew."
Sean with future brewer in arms, and colleague, Tuval.
Mike, loaner of drawknives and other sharp things!

Justin, floor joist helper, and Bill of wall-building exploits.

Lance and Lisa and Andrew, all NOC types.
The Master sampling his own cooking!




54: Finishing the roof!

I'm happy with the roof after deliberating what to do all summer. No time to use a froe and make my own shingles. It would be out-of-character and against the principles I've applied here to buy them at Cashiers prices. Cedar shakes are very expensive. Asphalt shingles would look just, well, wrong. That leaves tin as an appropriate, fitting building material that has adorned the scalp of many a cabin since the late 19th Century.

Thursday, Jon Ogburn came up the holler to help me with the roof. Although I've mostly done everything with the help of others and many things by myself, I'm (a) sprinting to a stopping point and wanted to get this done, (b) not hugely fond of being on roofs, and (c) aware that the charming lack of angular perfection has implications when placing perfectly square panels of tin. Plus, Jon's fun to have around, and he brings an appreciation of all the hand-tool work I've done to bring the cabin this far -- he worked with an Amish roofer for years. Like me, he makes concessions (used a battery drill). I just wish he'd worn his black wide-brimmed hat yesterday!



Tobias came by while Jon roofed and I was building log furniture. These guys represent two ends of the project. Tobias felled the trees, and Jon finished the roof.


Here's Jon, with his splendid, gleaming tin roof in the background. Until it fades a bit, you'll be able to see it from space.




53: Cutting a board for my roof!



Other boardcutting posts:
Handsaw (small)
Ralph Morgan interview
Handsaw (big, on the roof!)
Sawyer (ripping a log with a chainsaw)
Big saw!
Tale of two saws, part 1, part 2, and part 3

52: Interview with our very own local sawmill man

This interview speaks for itself.  Thanks Ralph!



Click Here to see Ralph in action!

51: Rafters and roof planks!

Last weekend, I hung all of the rafters, working alone.

As discussed in Chapter 38, I made some mistakes, but I corrected them. This weekend, Mark showed up at 7am on Saturday, and we got one side of the roof decked with rough-sawn 1x8 pine planking. I couldn't have done it without his help. Later in the morning, I managed to get the other side up by myself, but it was closer to the ground. Sunday, John helped keep me safe working on the steep pitch, moving the rope around and holding the ladder -- it was essential, if not to my actual safety then to my level of confidence.

Both of these guys were generous with their time, and it was more fun because they were there.

Here are some photos!







During the evenings this week, I'll get drip edge nailed down, douse the roof with Penetreat, tack down 30-weight felt paper, and box in the door and windows. Thursday, I'll stay home and help nail down tin on the roof! Oh, to use cedar shakes -- but using a froe to make those would take me a month.

50: Rafters!

I'm holding the camera crooked -- the cabin is level!

I managed to put up all but the most outlying rafters all by myself! I notched the last two logs, the top plate logs, on the ground, cutting them on 24" centers all the way along. I did that by snapping two chalk lines an equal hight from the bottom of the log, not the top, helping to insure a similar hight for the top of the rafters over which the roof planking will cross.

Then, I sat the two rafters on top of the other, bigger 15' top plate rafters and along the crest of the load-bearing walls. I tried my best to rotate the logs so that the notches would angle up, toward the ridge beam in the center, toward which the rafters would travel.

Using a bevel, I figured the angle to cut the high end and tail of each rafter, the angle being slightly different for each side. I used a chain saw on the ground as a chop saw. The left-side rafters are 110 inches, and the ones on the right are a full ten feet. This differential was necessary to reduce the overhang above the left-side window. Who wants to look out at an eave? There'll still be about two feet of overhang on that side. On the long side, the front rafter had to be shorter to accommodate a birch tree. I'm hoping we can angle the tin around that tree.

One mistake -- I somehow reversed the direction of one of those pre-notched top plate logs. That might have happened in the pre-dawn hours when I was working in the beam of a headlamp.

So, only after hanging several rafters on one side did I discover that they don't line up with their partners rising to meet them from the other pre-notched, pinned-down wall. Doh!

I fixed this next to the verticals by creating new notches with the crosscut saw and big framing slick. That razor sharp 7 pound chisel made it so easy I wish I'd just notched them all up on the wall.

This would be a deal-breaking design flaw on a residence being permitted according to code. Fortunately, this is an outbuilding that doesn't have to meet a living-space criteria. Also, the full-dimension 3x8 ridge beam is both sturdy enough and supported from below, and the roof is small, and log walls are extremely unlikely to spread, so collar ties won't be necessary and I think it'll be fine. I may strap them from below and up/over the other side of the beam, though.

I could simply add a couple of rafters on the opposing side near the middle of the span. This would look like overkill but might do the trick.

49: Ridge Beam!


Yesterday, I drove to Ralph Morgan's sawmill, four miles down the road in Webster, to pick up the huge timbers that will somehow be cut and hoisted and shaped and seated into notches to frame the roof. Overloaded, my truck crept home and up the steep road into the holler. Unloading it all took time. Even though the beams, although not cultivated on my own land, were legitimately cut and sawn locally, I felt a need to pull a draw knife down the sharp edges, softening the look and feel and roughing up the overall impression to better match the un-hewn log walls.

Unsure where to stack and store a 3x8 (full dimension, more like a 4x10) 15' beam, I decided to drop it into the bed I made -- I had pre-cut notches in the top of the vertical poles, made from the log that Tobias milled so expertly with his saw, travelling up to support the beam but also securing each wall log on their journey toward the roof's peak.

The beam is green. This green beam is not lean. It weighs enough to be mean. I watched Ralph cut it from a massive chunk of white pine. It probably weighs 120-150 pounds. Fine for carrying around but not so ideal for lifting overhead on a ladder. I called my neighbor (up another branch of the holler), Eric, for help with the mean green beam: "Hi Kathleen, how are y'all this evening?"

Kathleen: "We're fine." Matter of fact. Cheerful. Good.

Me: "I hope I didn't hold you up on the way in!" She had driven in behind me and all the lumber, catching up to me on the gravel road before our drives separated. "So, what are y'all up to?" Fishing.

Kathleen: "Oh nothing, what's up?" Good -- not bathing Molly or still eating. I explain that I only need him for a second, but... "Eric! Will's on the phone!"

I ask Eric if he has 5 minutes to help me lift the beam into place, that he'd be home 15 minutes after leaving his front porch. You see, he's helped me out so much, and he worked till after dark recently, helping me string the 20x40 foot tarp way up in the air, above the cabin, to protect the Penetreat from leaching out in the rain. I say, "this'll be a real 5 minutes, not a Will-Gatlin-Five-Minutes, which translates into something not always popular among our overly-tolerant-already wives. Actually, Kathleen's really cool, and Eric's really generous, but I didn't want to take advantage of my great neighbors, and this was the epitome of short notice.

We got it up, and he got home. One underlying theme of this whole project remains the generosity and camaraderie of my friends.

48: Progress under a tarp


I took this snapshot at 6:45am with a cell phone. I'll post better images soon. As a quick update with no particular emphasis on finer descriptions, here's a list of stuff I've done this week, largely in the pre-dawn hours with a headlamp:
  • Cut two windows
  • Hewn window sills
  • Chiseled walls and erected split/milled vertical center support poles to hold the ridge beam
  • Cut 3" notch in the top of said support pole
  • Drilled all 4 walls and pegged top three logs with rebar
  • Framed interior sides of door and windows
  • Milled door step
  • Cut 2" notches on 24" centers along second top plate logs to hold rafters

In the next two weeks, I'll:
  • Box frame the exterior sides of door and windows
  • Notch and pin down the 2 top plate logs on the load-bearing sides
  • Set the ridge beam, a full-dimension 3x8 milled by Ralph Morgan down the road
  • Install 18 10'-long full-dimension 2x6 rafters by pinning them to the ridge beam and dropping them into the notched top plate, creating an approximately 3-12 pitched roof
  • Plane the window sills
  • Install 16'-long rough-sawn 1x8 planking across the rafters creating a full underlay
  • Tack down 30 weight felt, drying it in
  • Remove the tarp protecting my borate-solution treatment from rain
  • Cut the tails even
  • Install tin roofing




47: Walls

The last few weeks have been swift, productive, and mostly fun, but there's been little time to write about any of it. College started, and I both teach and counsel students, not to mention all the committee work, training retreats, launching a new program with nine new staff, and all the administrivia. Kindergarten also started, and Big Abel has shown daily enthusiasm and courage, carrying a backpack bigger than his back, rocketing into the world from my truck in the mornings, across the sidewalk, away, far away. I usually drop him off on the way to work, because Sloan doesn't teach then, and baby Angus has a different schedule.

Two weeks ago Sunday, Mark and Bill came to help lift the huge big top plate logs, the ones that bridge the windows and door and support the doubled top-top-plate that I'll deeply cut on 24-inch centers to hold 18 rough-sawn rafter tails, milled locally by Ralph Morgan down the road, more snugly than would notches and even joist hangers.

Mark got to use hand tools this time, instead of his big 4x4 Tacoma. The right tool being selected for the right job, that truck was more useful than ever the day we brought these monster logs up to the clearing above the site. I scooted them down the MTB trail to the cabin alone, but without the muscle of an internal combustion engine, I needed help to hoist them up above six feet.

Bill is an interesting guy. A literary man, he's been a journalist, a graphic designer, and a generally thoughtful and creative guy. Not particularly outspoken, at least in a loud or dominant way, when he contributes to a conversation it's usually reflective, keenly observant, mildly ironic, and pretty funny. I always listen up. Almost seven feet tall, Bill's handy for the work we're doing today, and he tolerates all the same-old-chatter about his height.

I collect colloquialisms, and Bill has some good ones. He's not afraid to use them, either. Around here, like anywhere in any culture in any language, you greet somebody with some version of "Hello, how are you doing?"

Bill rumbles up the gravel road into the holler and slouches up to the treehouse and climbing wall, past the fire pit, then down the trail to Mark and I, and before meeting Mark for the first time, asks me, "How's-yer-ma-an-them?"

The phrase flows like one, uninterrupted, five-syllable word, the inflection on "ma" and "them." I say I'm fine, and so are Sloan and the boys, because that's what he means. Bill doesn't always talk like that, but like me he enjoys language and has fun with it, and his roots are from the Tennessee mountain lumber country and from right here in these hills and hollers. Bill can pull it off like a local. Not like Mr. Wilson or other older ones, but good enough.

I try to infuse my South Carolina foothills twang with such localisms, its usually nasal, flat "i" already smoothed with the longer vowels of Charleston and even the comforting, soft sounds of the Shenandoah where "house" is pronounced "hoess," and my own kindness to consonants, with less success. I've just lived too many places where I like the speech. I can't seem to emulate the local accent, even though it's closer to my original foothills way of speaking than not. Trying, I'm always respectful but not very successful.


This is heavy, maybe 300 pounds. It's going across the top of the door.

Real men = no need for mechanical assistance!

Lovin' this saw.

Bill is so tall, he can use the saw without climbing!
Sugar, Big Abel, and Baby Angus cooked a great lunch, and my friends earned it for sure.
